Image Sensor

1/3" CMOS Sensor

Max Resolution

3200*1800

Effective Pixels

6.0MP

Compression Standard

H.264/H.265

Framerate

25fps

Bitrate

Main Stream: 256Kbps ~ 10Mbps

Sub Stream: 68Kbps~3072Kbps

SNR (dB)

49.3dB

Min. Illumination

0Lux (light ON)

Interface Type

M12

Lens

2.8mm

FOV

2.8mm:H 104.3°, V 57.9°, D 121.8°

Function

Audio Codec

G.711U/G.711A (default)

Exposure Control

Auto, HLC, BLC

White Balance

Auto

Gain Control

Auto

OSD Information Setting

Large font OSD, OSD flashing on alarm, OSD position settings

SNTP

Support

Schedule Reboot

Support

Smart Defog

Support

Motion Detection

Support Humanoid Detection & Vehicle Detection

Image Setting

Support Saturation, Brightness, Contrast, Sharpness adjustment

Image Style

Standard, Soft, Transparent

Day and Night Function

Auto, Always Black & White, Always Color, Scheduled Color

Privacy Mask

Support up 8 areas

Night Vision Optimization

Support

WDR

Support

Screen Settings

Screen mirroring, Screen flipping

IP Adaptation

Support automatic adaptation of IP address (Optional)

Alarm Method

Email Alarm, Client Alarm

Remote Operation

System, Audio and Video, Image, Alarm, Network management

VQC Technology

Support

SAFE Function

Support

Network

Ethernet

10/100Mbps Ethernet

Stream

2x Streams

Network Protocols

HTTP, TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS

ONVIF

Standard ONVIF

Network Transmission

CloudSEE 3.0

Browser

IE8+, Chrome18+, Firefox5.0+, Safari5.02+

User

Up to 13 Users

App

Support iOS/Android

General

Lights

4 White LEDs + 4 IR LEDs

IR Distance

Up to 30 Meters

White Led Distance

Up to 20 Meters

Waterproof Level

IP67

Power Supply

DC12V or PoE (IEEE802.3af)

Power Consumption

<3W (During Day); <9W (At Night)

Working Temperature

-30℃~60℃(-22℉~140℉)

Working Humidity

5% ~ 93% Rh

Color/Material

Black & White/Metal ball+ Plastic

Dimensions (W x H x D)

108x104x106mm

Weight

360g

Installation Method

Ceiling Mount
