Image Sensor

1/1.8" CMOS Sensor

Max Resolution

3200x1800

Effective Pixels

6.0MP

Compression Standard

H.264/H.265

Framerate

25fps

Bitrate

Main Stream: 294Kbps ~ 8192Kbps

Sub Stream: 58Kbps~ 2356Kbps

Min. Illumination

0Lux (light ON)

Lens

Interface Type

M16

Lens

4mm,1/1.8’’ F1.0  large aperture lens

FOV

H 93°, V 50.5°, D 110.2°

Function

Audio Codec

G.711U (default)/G.711A

Gain Control

Auto

Digital 3D Noise Reduction

Support

OSD Information Setting

Large font OSD, OSD flashing on alarm, OSD position settings

Motion Detection

Support Humanoid Detection

Image Setting

Support Saturation, Brightness, Contrast, Sharpness adjustment

Privacy Mask

Support up 8 areas

WDR

120dB

Screen Settings

Screen mirroring, Screen flipping

Intelligent Analysis

Support human detection, Region Intrusion Detection, Line Crossing Detection,defocus detection;dideo occlusion;

Alarm Method

Email Alarm, Client Alarm

Remote Operation

System, Audio and Video, Image, Alarm, Network management, Storage management, Intelligent Analysis

Audio Function

Built-in Mic and Speaker

SD Card

Support(MAX 512G)

VQC Technology

Support

Network

Ethernet

10/100Mbps Ethernet

Stream

2x Streams

Network Protocols

HTTP, TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS

ONVIF

Standard ONVIF

Network Transmission

CloudSEE 3.0

Browser

IE8+, Chrome18+, Firefox5.0+, Safari5.02+

User

Up to 13 Users

App

Support iOS/Android

General

Lights

4 White LEDs

Distance

Up to 50 Meters

Waterproof Level

IP67

Power Supply

DC12V or PoE

Working Temperature

-30°C ~ 60°C

Working Humidity

10% ~ 90% Rh

Color/Material

Black and White/Plastic and Metal

Installation Method

Wall or ceiling mount
