  • JVS-XD2508-HL10V

›

JVS-XD2508-HL10V
8CH 5MP XVR
Message
Features
Specification
Accessories
Download

Key Features

• AHD, TVI, CVI, CVBS, IP video input.

• Automatic networking support.

• Cloud services, P2P.

• H.265+ video compressions.

• Third-party network cameras supported.

• Support IVP

Specifications
ModelJVS-XD2508-HL10V
Video and Audio
Analog Camera Input8Channel, BNC
HDCVI Camera1080P@25/30fps, 720P@25/30fps
AHD Camera5MP, 1080P@25/30, 720P@25/30fps
TVI Camera1080P@25/30, 720P@25/30fps
CVBS CameraPAL/NTSC
IP Camera InputUp to 5MP
Video Port ConfigurationFull HD: 8CH
Hybrid: 4CH+4CH
Full Network：8CH
Audio In/Out4/1, RCA
Two-way Talk1CH RCA
Recording
CompressionH.264+/H.265+
Resolution5MP,1080P, 1080N, 720P, WD1
Record RateMain Stream:5MP(1~20fps),1080P(1~25fps),1080N/720P/960H/D1(1~25fps)
Sub Stream: D1/CIF(1~8/12fps)
Record Mode

Manual, Schedule (General, Continuous), MD (Motion Detection, Video Loss, IVP),

 Alarm Device

Audio Compression                G.711U
Display
Interface1x HDMI, 1x VGA
Resolution1280x1024, 1024x768, 1280x800, 1440x900, 1920x1080
OSDDevice ID, Time, Record Setting, Alarm Setup, Audio,Camera Title
Network
Interface1 RJ45 Port (100M)
Network FunctionTCP/IP, DHCP, DNS, DDNS, HTTPS, HTTP,
Smart PhoneiPhone, Android
InteroperabilityONVIF
Playback and Backup
Playback8CH
Search ModeTime /Date, Alarm, MD, IVP, Auto, Scheduled
Playback Function

Day View, Hour View, Back Step, Rewind, Pause, Play,Fast Forward, Slow, Step, Snap,

Sound ON/OFF, Zoom,Backup to U-Disk

Backup ModeUSB
HDD
Interface Type1 SATA Interface
CapacityUp to 6 TB
General
Power SupplyDC12V
Consumption≤8W
Working Temperature00C~ 550C
Working Humidity10% to 90%
Dimensions345x275x75mm
Weight≤1.4 kg
