JVS-N517-TDL
5MP Bullet Full-Color Audio IP Camera
Message
Features
Specification
Accessories
Download

Features

  • Light's On When People Come, Light's Off When People Leave

  • Double Wick, Four warm light, Four infrared

  • Support Humanoid Detection

  • Support Region Intrusion Detection, Line Crossing Detection, Video Tampering Detection

  • Equipped With unique VQC (Video Quality Catalyst) Technology

  • Built-in MIC and Speaker

  • Support SD Card(256GB)

Specifications
Video
Image Sensor1/2.66" CMOS Sensor
Max Resolution2880x1620
Effective Pixels5.0MP
Compression StandardH.265/H.264
Frame Rate25fps
Bit Rate256Kbps~8192Kbps
SNR (dB)52dB
Min. Illumination0Lux   (IR ON)
Lens
Lens3.6mm(M12)
FOVH:95.1°, V:48.5°, D:113.5°
Lights4   Warm Light LEDs + 4 IR LEDs
IR DistanceIR: Up to 50 MetersWarm Light: Up to 30 Meters
Function
Exposure ControlAuto
White BalanceAuto
Gain ControlAuto
Image Enhancement3D DNR
Advanced OSDSupport OSD large font function, OSD flashing on alarm, OSD and time to set the position   separately
Motion DetectionSupport Humanoid Detection
Image SettingFlip, Saturation, Brightness, Contrast, Sharpness
Day and night   functionDay and night automatic switching
Privacy MaskSupport up to 8 areas
Intelligent   AnalysisRegion Intrusion Detection, Line Crossing Detection, Video Tampering Detection
Alarm Method Email Alarm, Client Alarm
Remote OperationSystem, Audio and video, Image, Alarm, Network   management
SD CardSupport(256GB)
Expansion   InterfaceBuilt-in MIC and Speaker
Network
Ethernet10/100M Ethernet ,1 RJ45
Stream2x Streams
ProtocolsHTTP, TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS
ONVIFStandard ONVIF
Network   transmissionCloudSEE 2.0, GB28181
BrowserIE8+, Chrome18+, Firefox5.0+, Safari5.02+
UserUp   to 13 Users
AppSupport iOS/Android
General
Power SupplyDC12V or PoE
Power Consumption<3W (During day); <6W (At night)
Working Temperature-20°C  ~ 60°C
Working Humidity10% ~ 90% Rh
Material Black and white/Plastic
Dimensions (WxHxD)104x98x184(mm)
Weight280g
WaterproofIP67
