Video |
Image Sensor | 1/3'' CMOS Sensor |
Max Resolution | 2560x1440 |
Effective Pixels | 4.0MP |
Compression Standard | H.264/H.265(Default) |
Framerate | 25fps |
Bitrate | Main Stream: 256Kbps ~ 8192KbpsSub Stream: 68Kbps~1024Kbps |
SNR (dB) | 45dB |
Min. Illumination | 0Lux (IR ON) |
Lens |
Lens | 3.3mm-10.5mm Motorized Zoom |
FOV | Horizontal: 94.5° (W) -29.4° (T)Vertical: 50.5° (W) -16.5° (T)Diagonal: 111.4° (W) -33.5° (T) |
Function |
Character Extraction | Character Recognition, Character Extraction Alarm |
OSD Overlay Display Settings | The Default Display Character Information; The Default Alarm Flashes; The Default Font Color Is Yellow, And Can Be Set to White, Yellow, Green, And Blue; The Default Font Size Is 48, And Can Be Set To 16-48; The Default Detection Area Is Not Superimposed |
Area Drawing | Support Drawing Up To 4 Detection Areas |
Linkage Setting | By Default, Alarm Is Sent to The Client, OSD Flashes, And SD Card Records Are Recorded |
Arming Period Setting | Default Enables Full-Time Arming.Supports Setting Arming for Any Time Period |
Audio Codec | G.711U/G.711A (Default) |
Exposure Control | Auto, HLC, BLC |
OSD Information Setting | Large Font OSD, OSD Flashing on Alarm, OSD Position Settings |
Schedule Reboot | Support |
Smart Defog | Support |
Motion Detection | Support (Humanoid, Vehicle, Non-motorized Vehicle) |
Image Setting | Support Saturation, Brightness, Contrast, Sharpness Adjustment |
Image Style | Standard, Soft, Transparent |
Day and Night Function | Auto, Always Black & White, Always Color, Scheduled Color |
Privacy Mask | Support up to 4 Areas |
Night Vision Optimization | Support |
WDR | Support |
Screen Settings | Screen Mirroring, Screen Flipping |
IP Adaptation | Support Automatic Adaptation IP Address (Optional) |
Alarm Method | Email Alarm, Client Alarm, FTP Alarm, HTTP Alarm |
Network |
Ethernet | 10/100Mbps Ethernet |
Stream | 16x Streams |
Network Protocols | HTTP, TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS |
ONVIF | Standard ONVIF |
Network Transmission | CloudSEE 2.0 |
Browser | IE8+, Chrome18+, Firefox5.0+, Safari5.02+ |
User | Up to 13 Users |
App | Support iOS/Android |
General |
Lights | 6 White LEDs + 6 IR LEDs |
IR Distance | Up to 10 Meters |
Waterproof Level | IP67 |
Power Supply | DC12V/1A or PoE (IEEE802.3af) |
Power Consumption | <3W (During Day); <6W (At Night) |
Working Temperature | -20°C ~ +60°C |
Working Humidity | ≤93% Rh |
Color/Material | Black & White. Aluminum Alloy, PC + ABS |
Dimensions (W x H x D) | 104x98x184mm |
Weight | 280g |
Installation Method | Wall or Ceiling Mount |
